Getac UX10

Manufacturer: Getac
Fully Rugged Tablet 10.1"FHD Windows 10 Pro / IP65 / MIL-STD-810H
Description
  • 10.1" Wide Viewing Angle TFT LCD WUXGA (1920 x 1200) 1,000 nits LumiBond® display with Getac sunlight readable technology
  • 1.8m drop-resistant, MIL-STD-810H and IP66 certified
  • Intel Core i5/i7 12th Gen
  • Available with GPS and LTE
  • Optional dedicated keyboard
In stock
Go to B2B shop

Description





THE ULTIMATE SECURE RUGGED TABLET

An optional hard handle makes the UX10 easy to grip and carry, allowing you to take the computing power you require to the place it is most needed. A detachable keyboard with retractable hard handle further optimises worker productivity. For total security in authenticating users, the UX10 has an optional integrated fingerprint reader, smart card reader, magnetic stripe reader, an RFID reader, and can also offer a Windows Hello face-authentication camera.



THE CONNECTED TABLET

The UX10 seamlessly supports digital transformation, offering digital connectivity through BT, WiFi, and optional 4G LTE. An optional RS232 port can support legacy equipment. An optional RFID reader allows information feed-back into the management system. All these functionalities ensure the UX10 stays connected no matter whether outdoors or indoors.



THE ‘ALWAYS-ON’ TABLET

In a world where devices need to work 24/7/365 power-up continuity is essential – in portable devices that means a focus on battery configuration. The UX10 offers a range of battery configurations and options, including an optional high capacity battery and an optional bridge battery that ensures a ‘hot swap’ capability. In effect you need never power-down the UX10, making it ideal if the device is pooled between workers or required across multiple work shifts.



THE USABLE-IN-ALL CONDITIONS TABLET

Drop resistance and temperature tolerance aside, the LumiBond® screen ensures usability in all conditions. 1000 nits of brightness make the display readable even in sunlight, whilst rain and glove touch capability guarantee visibility and productivity in even the most extreme conditions.



BEYOND EXPECTATIONS

Accidents can take your equipment out of service when you least expect it, especially in a rugged environment, which can cause costly equipment downtime. That is why Getac has introduced accidental damage as standard under our new Bumper-to-Bumper warranty, to help minimize your enterprise IT costs. Bumper-to-Bumper is your hassle-free guarantee, supported by the best Pack & Collect logistics service in Europe, and rapid repair and return by Getac’s in-house experts. That means you can depend on us to have your unit back in service within days.



Basic parameters

CPU

Intel® Core™ 12th Gen.

Water and Dust Resistance IP66
Display

10.1" LCD WUXGA (1920 x 1200) 1,000 nits LumiBond® with sunlight readable technology

Connectivity

Intel® Wi-Fi 6 AX200, 802.11ax, optional LTE / GPS

Battery

Li-ion (11.1V, typical 4200mAh) x 1
Optional: High capacity Li-ion (10.8V, 9240mAh) x 1

Certificates MIL-STD-810H, MIL-STD-461G
SSD

PCIe NVMe SSD

Operating

Temparature

-29°C to +63°C
Drops 1,8m drop resistant Warranty 36 months (accidental damage included)

Technical Specification

  • Getac UX10 G3 Technical Data
Generation

G3

Operating System

Windows 11 Pro

Mobile Computing Platform

Intel® Core™ i5-1235U Processor
Max. 4.4GHz with Intel® Turbo Boost Technology
- 12MB Intel® Smart Cache

Intel® Pentium™ 8505 Processor
Max. 4.4GHz with Intel® Turbo Boost Technology
- 8MB Intel® Smart Cache


Platform options:
Intel® Core™ i5-1245U vPro® Processor
Max. 4.4GHz with Intel® Turbo Boost Technology
- 12MB Intel® Smart Cache

Intel® Core™ i7-1255U Processor
Max. 4.7GHz with Intel® Turbo Boost Technology
- 12MB Intel® Smart Cache

Intel® Core™ i7-1265U vPro® Processor
Max. 4.8GHz with Intel® Turbo Boost Technology
- 12MB Intel® Smart Cache

VGA Controller

Intel® UHD Graphics

Display

10.1" Wide Viewing Angle TFT LCD WUXGA (1920 x 1200)
Protection film
1,000 nits LumiBond® display with Getac sunlight readable technology
Capacitive multi-touch screen

Storage & Memory

8GB DDR4
Optional: 16GB / 32GB DDR4

256GB PCIe NVMe SSD
Optional: 512GB / 1TB PCIe NVMe SSD

Keyboard

Power button
5 tablet programmable buttons

Pointing Device

Touchscreen
- Capacitive multi-touch screen
- Optional: Dual mode touchscreen (multi-touch and digitizer)

Expansion Slots

Optional (top side): 1D/2D imager barcode reader, or Serial port, or USB 3.2 Gen 1 Type-A port, or LAN port (RJ45) , or microSD or HF RFID reader i, or HDMI 2.0.ii
Optional (right side): LAN port (RJ45) or Fingerprint readeriii
Optional (back side): Smart card reader, or Bridge battery, or Bridge battery + Smart card reader iv

I/O Interface

FHD webcam x 1 v
8M pixels auto focus rear camera x 1
Audio in/out combo x 1
DC in Jack x 1
USB 3.2 Gen 2 Type-A x 1
Docking connector x 1
Thunderbolt™ 4 Type-C x 1
Optional: Windows Hello face-authentication camera (front-facing) x 1 v
Optional: RF antenna pass-through for GPS, WWAN and WLAN

Communication Interface

Optional: 10/100/1000 base-T Ethernet
Intel® Wi-Fi 6E AX211, 802.11ax
Bluetooth (v5.3) vi
Optional: Dedicated GPS with L1/L5 ix
Optional: 4G LTE mobile broadband with integrated GPS vii, viii, ix, x
Optional: 5G Sub-6 with integrated GPS vii, viii, ix
Dual SIM (Micro-SIM 3FF and e-SIM) vii, viii

Security Features

TPM 2.0
Kensington lock

Optional: Intel® vPro® Technology
Optional: HF RFID reader i, ii
Optional: Fingerprint reader iii
Optional: Smart card reader iv
Optional: Windows Hello face-authentication camera (front-facing) v

Power

AC adapter (65W, 100-240VAC, 50/60 Hz)
Li-ion battery (11.1V, typical 4200mAh; min. 4080mAh) x 1
Optional: High capacity Li-ion battery (10.8V, 9240mAh) x 1
Optional: Bridge battery iv

Dimension (W x D x H) & Weight

279 x 194.5 x 23.5mm (10.98" x 7.65" x 0.92") xi
1.22kg (2.68lbs) xi

Rugged Feature

MIL-STD-810H certified
IP66 certified
MIL-STD-461G certified xii
Vibration & 6ft (1.8m) drop resistant xiii
Optional: ANSI/UL 121201, CSA C22.2 NO. 213 (Class I, Division 2, Groups A, B, C, D) xiv

Environmental Specification

Temperature xv:
- Operating: -29°C to 63°C / -20°F to 145°F
- Storage: -51°C to 71°C / -60°F to 160°F
Humidity:
- 95% RH, non-condensing

Pre-installed Software

Getac Utility
Getac Camera
Getac Geolocation
Getac Barcode Manager xvi
Getac Driving Safety Utility (trial version)
Getac KeyWedge Barcode Reader Utility (trial version)
Optional: Absolute Persistence®

Optional Software

Getac Driving Safety Utility
Getac KeyWedge Barcode Reader Utility
Getac Device Monitoring System (GDMS)
Getac VGPS Utility xvii

Accessories

Battery (11.1V, typical 4200mAh; min. 4080mAh)
AC adapter (65W, 100-240VAC)
Capacitive stylus with tether

Optional:
Carry bag
Folio case
Battery (11.1V, typical 4200mAh; min. 4080mAh)
High capacity Li-ion battery (10.8V, 9240 mAh)
Multi-Bay charger (Dual-Bay)
Multi-Bay charger (Eight-Bay)
AC adapter (65W, 100-240VAC)
AC adapter (90W, 100-240VAC)
MIL-STD-461 AC adapter (90W, 100-240VAC)
DC-DC vehicle adapter (120W, 11-32VDC)
Digitizer pen
Capacitive stylus with tether
Protection film
Hard handle
Rotating hand strap with kickstand
Shoulder strap (2-point)
Shoulder harness (4-point; handsfree)
Detachable keyboard
Vehicle cradle xviii
Keyboard dock
Vehicle dock xviii
Office dock
100W Type-C adapter

Bumper-to-Bumper warranty

Accidents can take your equipment out of service when you least expect it, especially in a rugged environment, which can cause costly equipment downtime.
That is why Getac has introduced accidental damage as standard under our Bumper-to-Bumper warranty, to help minimize your enterprise IT costs.
Bumper-to-Bumper is your hassle-free guarantee. That means you can depend on us to have your unit back in service within days.

Standard
3 years Bumper-to-Bumper

  1. 13.56MHz contactless HF RFID reader (ISO 15693, 14443 A/B, Mifare and FeliCa™ compliant).
  2. 1D/2D imager barcode reader, Serial port, USB 3.2 Gen 1 Type-A port, LAN port (RJ45), HF RFID reader, MicroSD and HDMI 2.0 are mutually exclusive options.
  3. Fingerprint reader and LAN Port are mutually exclusive options.
  4. Smart card reader, Bridge battery and Bridge battery + Smart card reader are mutually exclusive options.
  5. FHD webcam and optional Windows Hello face-authentication camera (front-facing) are mutually exclusive options.
  6. Bluetooth performance and connectable distance may be subject to interference with the environments and performance on client devices, users may be able to reduce effects of interference by minimizing the number of active Bluetooth wireless devices that is operating in the area.
  7. One physical SIM card slot and one eSIM.
  8. Network service may vary depending on local telecommunication providers.
  9. Supports GPS, GLONASS, Galileo, BeiDou and QZSS.
  10. Units with 4G LTE option come with an embedded SIM card slot.
  11. Weight and dimensions vary from configurations and optional accessories.
  12. MIL-STD-461 90W AC adapter sold separately.
  13. Drop test results vary from configurations and optional accessories.
  14. Available with limited configurations and environment conditions.
  15. Tested by an independent third-party test lab following MIL-STD-810H.
  16. Available when barcode reader option is selected.
  17. Models require either embedded or standalone GPS module.
  18. Gamber Johnson and Havis vehicle docks are e-mark certified.

Information provided herewith is for reference only, available specification shall be subjected to quotation by request.
