Durabook R10

Name: Durabook R10
Brand: Durabook
SKU: Durabook R10

new

Fully Rugged Tablet | 10.1" FHD 800 nits | MIL-STD-810H | IP66

Description

Display: 10.1" FHD 1000 nits, sunlight readable
Resistance: 1.8m drop, MIL-STD-810H, IP66
Operating temperature: from ‑29°C to +63°C
RAM: up to 32 GB
Memory: PCIe SSD 256GB/512GB/1TB/2TB
OS: Windows
Gpu: Dedicated graphics card
Guarantee: 36 months with the possibility of extension

Datasheet (1.76 MB)

Product out of stock

Product intended for professional use only

Datasheet (1.76 MB)

Go to B2B shop

Description
Basic parameters
Technical Specification
Pliki do pobrania

Description

Basic parameters

CPU	Intel® Ultra™	Water and Dust Resistance	IP66
Display	10.1” LCD (1920x1200) 1000 nits DynaVue® sunlight readable display with capacitive multi-touch screen	Connectivity	Intel® Wi-Fi, optional LTE / 5G / GPS
Battery	Main battery: Li-Ion, 11.4V, 4400mAh, 8 hours Optional hi-cap battery Li-Ion 11.4V, 8700mAh,16 hours Optional bridge battery: 1 minute swap time	Certificates	MIL-STD-810H, MIL-STD-461G
SSD	NVMe PCIe SSD	Operating Temparature	From -29°C to +63°C
Drop	Resistant from 1.8m	Warranty	36 months

Technical Specification

Rugged Specs

	MIL-STD-810H certified (Drop, Shock, Vibration, Rain, Dust, Altitude, Freeze/Thaw, High/Low Temperature, Temperature Shock, Humidity, Explosive Atmosphere, Salt Fog)
	MIL-STD-461F certified (Conduction, Radiation, Conducted Susceptibility, Radiated Susceptibility)
	Optional ANSI/UL 121201, Class I, Division 2 6′ drop 26 faces IP 66 certified Magnesium alloy chassis Port covers Sunlight readable display Optional swappable battery technology

Tech Specs

Display	10.1” TFT LCD WUXGA (1920 x 1200) 1000 nits DynaVue® sunlight readable display with capacitive multi-touch screen Optional with digitizer User selectable touch mode for Finger/Water, Glove, or Stylus programmable function Support Microsoft Pen Protocol (MPP) 1.51 active pen function
Operating System	Windows® 11 Pro 64-bit
Processors	Intel® Core™ Ultra 7 268V, vPro Enterprise (32GB RAM, 12MB Cache, up to 5.0 GHz, 8 cores, 8 threads, with Intel® AI Boost NPU up to 48 TOPS) Intel® Core™ Ultra 7 266V, vPro Enterprise (16GB RAM, 12MB Cache, up to 5.0 GHz, 8 cores, 8 threads, with Intel® AI Boost NPU up to 48 TOPS) Intel® Core™ Ultra 7 258V (32GB RAM, 12MB Cache, up to 4.8 GHz, 8 cores, 8 threads, with Intel® AI Boost NPU up to 48 TOPS) Intel® Core™ Ultra 7 256V (16GB RAM, 12MB Cache, up to 4.8 GHz, 8 cores, 8 threads, with Intel® AI Boost NPU up to 48 TOPS) Intel® Core™ Ultra 5 238V, vPro Enterprise (32GB RAM, 8MB Cache, up to 4.7 GHz, 8 cores, 8 threads, with Intel® AI Boost NPU up to 40 TOPS) Intel® Core™ Ultra 5 236V, vPro Enterprise (16GB RAM, 8MB Cache, up to 4.7 GHz, 8 cores, 8 threads, with Intel® AI Boost NPU up to 40 TOPS) Intel® Core™ Ultra 5 228V (32GB RAM, 8MB Cache, up to 4.5 GHz, 8 cores, 8 threads, with Intel® AI Boost NPU up to 40 TOPS) Intel® Core™ Ultra 5 226V (16GB RAM, 8MB Cache, up to 4.5 GHz, 8 cores, 8 threads, with Intel® AI Boost NPU up to 40 TOPS)
Memory	16GB up to 32GB on Package (LPDDR5X)
Storage	256GB NVMe PCIe SSD Optional 512GB/1TB/2TB NVMe PCIe SSD Optional OPAL 2.0 SSD
Graphics	Intel® Arc™ 140V GPU (for Intel® Core™ Ultra 7 CPU) Intel® Arc™ 130V GPU (for Intel® Core™ Ultra 5 CPU)
Camera	Integrated 5.0 MP IR camera for Windows Hello with dynamic shutter design Optional FHD webcam for front camera Integrated 11.0 MP rear auto-focus camera with flash and dynamic shutter design
Audio	Integrated microphone x 2 Intel® High Definition Audio Compliant Integrated speaker x 1 Keyboard volume and mute controls
I/O Interfaces	Thunderbolt 4 (type C) x 1 USB 3.2 Gen2 (type A) x 1 Audio in/out (combo jack) x 1 microSD card (microSDXC) x 1 10/100/1000 Ethernet (RJ45) x 1 Docking connector (20-pin Pogo) x 1 Dual SIM (Nano SIM & eSIM) DC-In jack x 1 Optional USB 3.2 Gen1 (type C) x 1³ Optional USB 3.2 Gen1 (type A) x 1³ Optional serial port (RS232/RS422/RS485: D-sub,9-pin) x 1³ Optional 1D/2D barcode reader x 1³ Optional 2nd 10/100/1000 Ethernet (RJ45) x 1³ Optional smart card reader x 1⁴ Optional RF antenna pass-through for GPS, WWAN, and WLAN
Expansion Slots	Optional magnetic stripe reader Optional smart card reader⁴ Optional smart card reader with LF/HF-RFID (NFC)⁴ Optional LF/HF-RFID (NFC)⁴ Optional UHF-RFID (NFC)^{2, 4}
Keyboard & Input	7 buttons (4 user-definable keys)
Communications	Integrated 10/100/1000 Ethernet Intel® Wi-Fi 7 BE201 (802.11 be) Bluetooth® V5.4 Optional dedicated GPS module (UBLOX-NEO-M9N)¹ Optional 4G LTE multi-carrier mobile broadband with integrated GPS¹ Optional 5G with integrated GPS¹ Optional RF antenna pass-through for GPS, WWAN, and WLAN
Security	Intel® vPro® Technology (per CPU options) Secured-core PC TPM 2.0 NIST BIOS compliant IR Camera (support Windows Hello) Stealth mode Kensington lock Night vision mode Optional fingerprint scanner² Optional smart card reader⁴ Optional LF/HF-RFID (NFC) reader⁴ Optional UHF-RFID (NFC) reader^2,4
Power	AC adapter: 100-240V, 50Hz-60Hz, 65W Main battery: Li-Ion, 11.4V, 4400mAh, 8 hours⁵ Optional hi-cap battery: Li-Ion, 11.4V, 8700mAh, 16 hours⁵ Optional bridge battery: 1 minute swap time⁶
Environment	Temperature Operating: -29°C ~ 63°C / -20°F ~ 145°F Storage: -51°C ~ 71°C / -60°F ~ 160°F Humidity: 5% ~ 95%
Dimension & Weight	265 mm (L) x 189.5 mm (W) x 21.2 mm (H) 1.2 kg
Warranty	3-year limited warranty standard
